Description
Ubiquiti NanoSwitch Outdoor 4-Port PoE Passthrough Switch
N-SW
Specifications
- Dimensions (Excluding Mount): 196.4 x 93.5 x 32.4 mm ( 7.73 x 3.68 x 1.28″)
- Weight: 271 g (9.6 oz)
- Enclosure Characteristics: White Polycarbonate
- Total Non-Blocking Line Rate: 4 Gbps
- Typical Power Consumption: 1.5W
- Max. Power Consumption: 30W
- Power Method: 24V, 2-Pair Passive PoE
- Networking Interfaces: (4) 10/100/1000 Mbps Ethernet RJ45
- Total Passive PoE Max Wattage: 24V, 2-Pair, 1A for 3 Ports (30W)
- Passive PoE Max Wattage per Port: 24V, 2-Pair, 1A per Port (24W)
- Passive PoE Voltage Range: 21.6 – 30V
- ESD/EMP Protection: ± 24kV Air, ± 24kV Contact
- Operating Temperature: -30 to 70° C (-22 to 158° F)
- Operating Humidity: 5 to 95% Noncondensing
- Certifications: CE, FCC, IC
